Technical Specifications
| Model |
VISCOFILL™ -1H |
VISCOFILL™ -2H |
| Output/Hour |
400 to 1200* |
600 to 1800* |
| Number of Nozzles |
1 Nos. |
2 Nos. |
| Fill Size*** |
50ml to 1000ml |
50ml to 1000ml |
| Servo Motor |
0.7 KW / 415Volts / 50 Hz. |
0.7 KW / 415Volts / 50 Hz. X 2 Nos. |
| Electric Specification ** |
1.5 HP / 415Volts / 50 Hz. |
1.5 HP / 415Volts / 50 Hz. |
| Machine Dimensions** |
925 mm (L) x 700 mm (W) x 710 mm (H) |
925 mm (L) x 700 mm (W) x 710 mm (H) |
| Net Weight |
120 Kgs. |
120 Kgs. |
| Change parts required |
Not Require |
Not Require |
| Electrical supply |
3 Phase + Neutral + Earthing |
1 Phase + Neutral + Earthing |
| Electrical load |
1 KW |
1 KW |
| Air Pressure : Minimum |
6 bar pressure 0.5 CFM |
6 bar pressure 0.5 CFM |
|
Container Neck Diameter** |
Minimum 28 mm *** |
|||
|
Container Size** |
Round Shape Flat / Square |
You have to provide sample and dimension with purchase order You have to provide sample and dimension with purchase order |
||
*Depends on Container size, fill size, Neck diameter of container, nature of liquid & operator etc. **
We can supply as per customer requirements. *** With help of change parts.
