Air Jet Bottle Cleaning Machine

Discriptions

‘GMP’s Airjet Bottle Cleaning Machine is compact and highly efficient machine with elegant look. This multi featured machine meets the GMP requirements of clean glass and plastic bottles & Jars for non-sterile products like Dry Syrup, Bulk Packing for Tablets & Capsules etc and found a method of cleaning each individual Bottle/Jar by air jet & vacuum.

Operation

Containers are fed in upright position on a scrambler and further fed to feed worm, where containers are automatically inverted. The synchronized mechanism feed the container one by one through a chamber which is under negative pressure. A series of nozzles blow air in the container at a high pressure. The dust is collected in dust collector box through exhaust fan. The container is further fed through the synchronized mechanism and feed worm. It is once again upright position and comes out duly cleaned for further operation.

Technical Specifications

Model	GAJCM-60	GAJCM-120
Out put / Hour*	2400 to 4000	3600 to 7000
Direction of Machine**	Right to Left
Electrical Specifications**	1 HP / 415 Volts / 50 Hz	1.5 HP / 415 Volts / 50 Hz
Cleaning Cycle	Air Pressure (Positive) & Vacuum (Negative)
Working height	860 to 910 mm

Salient Features
